Hobart ECOMAX504-C Undercounter Dishwasher and Glasswasher

Hobart ECOMAX504-C Undercounter Dishwasher and Glasswasher

SKU: HOB-ECOMAX504-C

Hobart ECOMAX504-C Undercounter Dishwasher and Glasswasher

Cycle Times* 60 / 120 / 180 seconds
Rack Capacity 60 /h
Tank Capacity 25 L
Water Consumption 2.0 L/rack
Wash Pump 0.34 kW
Tank Heating 1.8 kW
Booster Loading - Standard 1.8 kW (240 V)
Total Connected Load - Standard 2.2 kW (240 V)
Power Supply 240 / 50 / 1
Machine width 576 mm
Depth 604 mm
Height 820 mm
Loading Height 360 mm
Rack Size 500 x 500 mm

$4,541.00$8,370.00

Hobart ECOMAX504-C Undercounter Dishwasher and Glasswasher

With a high capacity of up to 60 racks per hour, this dishwasher is a reliable partner for club houses, bistros, and fast-food restaurants. The practical floor unit fits under every work counter.

  • Single-button control with digital temperature indication
  • Flat surface of control panel
  • 3 selectable wash cycles
  • Special hygiene programme for hygienic cleanliness
  • Rotating top and bottom wash system to distribute the wash water evenly over the dishes
  • Indented nozzles prevent blocking
  • Thermostop-function for guaranteed rinse temperatures
  • Removal of rinse arms without any tools
  • Easy access to all parts
  • Deep drawn rack track
  • Double-walled housing and front door
  • Tank strainer reduces soiling of the tank water
  • Integrated cycle counting, e.g. for control of water treatment system
  • USB connect for easier service access
  • Refill signal monitors fill level of external chemical containers with optional suction lances
  • WaterMark License WMKT21944

PRODUCT FEATURES:

  • 1 x plate rack P-18-12
  • 1 x cutlery box CB1
  • Rinse aid dispenser
  • Rinse pressure pump for optimum flow pressure
  • Heater with thermostat control
  • Electric cable (240 / 50 / 1 - 15amp plug & lead), flexible water supply hose and drain hose
  • Rear paneling

For machine protection the water hardness should not exceed 3°dH, if higher we recommend using a HOBART HYDROLINE water softener / treatment system.
