Waldorf 800 RN8100G-RB - 900mm Gas Target Top - Refrigerated Base

Overall Construction

Target top

• 3 piece heavy-duty cast iron top with fully machined surface
• Top plates and removable centre with integral spill protection design
• Casttop reinforced with integral heatfins for heat zone definition
• 45MJ dual ring cast iron burner with single control
• Full pilot and flame failure protection
• 50mm thick refractory brick lined burner box for high heat retention
• Welded hob surround with 1.5mm 304 stainless steel bull nose
• Splashback and side panels 1.2mm 304 stainless steel
• Front panels 0.9mm 304 stainless steel
• 2 vitreous enamelled spill trays
• Supplied with heavy-duty centre casting removal tool

Bench mount (supplied as –B model)

• Four 63mm dia. heavy-duty 1.2mm 304 stainless steel bench legs with adjustable feet.
• Adjustable height 80mm – 105mm

Cabinet base (supplied as –CB model)

• Fully modular for match suite finish
• Double skin 0.9mm 304 stainless steel interior and exterior
• Optional GN 1/1 4 position racking kit (1 or 2 cabinet bays)
• Up to eight 65mm GN 1/1 capacity
• 63mm dia. heavy-duty 1.2mm 304 stainless steel legs with adjustable feet

Leg stand (supplied as –LS model)

• Fully modular for matched suite finish
• Framed top for connection to Target Top
• 63mm dia. heavy-duty 1.2mm 304 stainless steel legs with adjustable feet
• Fullymodularframed stand shelfwith0.9mm304 stainless steelfinish
• Suitable for rear or through shelf gas connection to Target Top
• Quick assembly design (no tools required

Refrigerated base (supplied as –RB model)

• Self contained suite matched modular base
• Ventilated system with R134a refrigerant
• -2˚ to + 8˚C temperature (Tropical Climate rated)
• Two GN 1/1 drawers
• 100mm deep pan capacity
• Heavy-duty European telescopic drawer guides
• Magnetic drawer gaskets (replaceable without tools)
• 50mm fully foamed CFC free insulation
• 304 stainless steel exterior and interior
• Anti-corrosion treated evaporator
• No condensate drain required
• 63mm dia. heavy-duty 1.2mm 304 stainless steel legs with adjustable feet
• Condensing unit removable through front of unit for service
• Easy clean interior

Controls

Target top

• Large easy use control knob - heat resistant reinforced
• Easy view control settings on knob
• Variable high to low burner control
• Single control knob for burner and pilot system
• Flame failure pilot burner
• Manual pilot ignition for reliable operation

Refrigerated base

• Digital control electronic thermostat
• Automatic defrost
• Automatic evaporation of defrost water
• -2 to +8˚C temperature range
